RCX-3000 PEG
製品特長
PRODUCT FEATURE
・インテル® Core™ 200Sシリーズおよびインテル® Core™ プロセッサ(第14/13/12世代)（コードネーム : Bartlett Lake-S/Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake‐S）搭載、最大TDP 65Wプロセッサ対応
・最大給電が1800W対応設計による、900W仕様のNVIDIA®またはAMDへ2スロットフルレングスのGPUをサポート
・DC 16V～50V電圧入力、ソフトウェアイグニッション電源制御が完備
・PCIe 4.0 x8、PCIe x4構成で最大7本PCIe拡張スロットサポート可能
・M.2と2.5インチSSD各2枚でフロントアクセス可能、5G/WiFi/4G/LTE/GPRS/UMTS対応
・4K対応の4基DisplayPort、USB 3.2 Gen 2x2 Type Cポート、TSN対応の2基2.5G LANポート装備
・Allxonによるデバイスのリモート保護管理機能サポート（Out-of-Band Remote Management）
-
High-performance AI Inference Platform
・Intel® Core™ 200S Series and 14/13/12th Gen Intel® Core™ Processor (codename: Bartlett Lake-S/Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake-S) running with Intel R680E PCH, max 24-core 65W TDP 5.2GHz CPU supported
・4 DDR5 Memory, up to 128GB, optional supports ECC
・Supports performance hybrid architecture and advanced AI capabilities for smarter and faster applications
・Intel UHD Graphics 770 supports DirectX 12, OpenGL 4.5, OpenCL 3.0
・Optional delivers outstanding AI computing productivity supporting max 10752 CUDA Cores, 84 RT Cores, and 336 Tensor Cores, delivers 75.6 TFLOPS RT Core performance, and 309.7 TFLOPS Tensor performance
・High-speed data transfer : PCIe 4.0 (16GT/s), USB 3.2 Gen 2x2 Type-C (20G), USB 3.2 Gen 2 (10G), SATA III (6G), 2.5GigE LAN (2.5G), GigE LAN (1G)
-
Advanced Integration
・Fully supports 3-slot, 2-slot, single-slot & full-length discrete graphics card
・Intel Deep Learning Boost for accelerated AI performance
・Intel Turbo Boost Technology 2.0 accelerates processor performance on peak loads
・Supports Intel vPro, TPM 2.0, PXE, Wake on LAN for remote control
・Supports TSN and Intel TCC for real-time control
・Fully supports Intel OpenVINO toolkit for AI Computing
・Optional supports remote device Out-Of-Band management functions powered by Allxon
-
Flexible Configuration
・Flexible product configuration for project requirements
・Max 7 PCIe expansions : PCIe 4.0 x16, PCIe x8, PCIe x4
・PCIe expansions for multiple 10GigE M12 PoE+ LAN, 10GigE PoE+ LAN, 10GigE LAN, 10G SFP+, 2.5GigE PoE+ LAN, 2.5GigE LAN, 100W PoE++, M12 PoE+ LAN, PoE+ LAN, GigE LAN, LAN Switch, USB, or Discrete Graphics
・Max 1800W power budget optional supports levels of full-length discrete graphics, max 10752 CUDA Core Computing
・Multiple compact M.2 Key B, M.2 Key E, M.2 Key M connections for Storage and Expansion
・Flexible Wide Range Power options : DC 16V to 50 Power Input or AC 90V to 240V Power Input
-
Industrial Optimization
・EN50155 & EN50121-3-2 compliant
・ICE 61373 : Anti-shock, Anti-vibration
・Dual high-reliable Intel 2.5GigE LAN support TSN
・Trusted longevity supports
・Wide range power input facilitates indoor, outdoor, and even in-vehicle operating environments
・16-mode SW Ignition Power Control benefits for in-vehicle operation
・32 Isolated DIO, 4 COM RS-232/422/485
・3 External SIM sockets supports always-on 5G/WiFi/BT/4G/LTE/GPRS/UMTS Wireless Communication
・Remote Power Switch
製品仕様
Product Specifications
| システム | |
| プロセッサ
|
– 24-core Intel® Core™ 200S Series Processor (Bartlett Lake-S)
– 24-core Intel® Core™ i9/i7/i5/i3 Processor (14th gen, Raptor Lake-S Refresh)
– 24-core 13th Gen Intel® Core™ i9/i7/i5/i3 Processor (Raptor Lake-S)
– 16-core 12th Gen Intel® Core™ i9/i7/i5/i3 Processor (Alder Lake-S)
|
| チップセット | Intel® R680E |
| BIOS | AMI |
| SIO | IT8786E |
| メモリ | 4 DDR5 UDIMM, up to 192GB (ECC/Non-ECC) |
| OS | Windows 10/11, Linux |
| I/Oインタフェース | |
| シリアルポート | 4 COM RS-232/422/485 (ESD 8kV) |
| USB |
– 4 USB 3.2 Gen 2 Type A
– 1 USB 3.2 Gen 2×2 Type C (5V/3A)
|
| Isolated DIO | 32 Isolated DIO : 16 DI, 16 DO |
| LEDランプ | HDD, Power, OOB |
| SIMカード | 3 External SIM Card Sockets |
| 拡張スロット | |
| Mini PCIe | 1 Mini PCIe Socket for PCIe/USB/SIM Card |
| PCIe |
2 PCIe x16 Slot with PCIe 4.0 x8 Signal
3 PCIe x16 Slot with PCIe x4 Signal
|
| M.2 |
– 2 M.2 Key B Socket (2280/3042/3052, PCIe x2/USB3(Default)/USB2)
– 1 M.2 Key E Socket (2230, PCIe x1/USB)
|
| グラフィックス | |
| グラフィックス プロセッサ |
Intel® UHD Graphics 770/730 driven by Intel® Xe Architecture |
| インタフェース | 4 Independent displays : 4 DisplayPort, up to 4096 x 2304 @60Hz |
| ストレージ | |
| SATA | 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10 |
| M.2 | 2 Front-access M.2 Key M SSD Tray (2280, PCIe x4) |
| その他 |
– 2 Front-access 2.5″ SSD/HDD Tray
– 2 Internal Bracket 2.5″ SSD/HDD
|
| オーディオ | |
| コーデック | Realtek® ALC888S-VD, 7.1 Channel HD Audio |
| 端子 | 1 Mic-in, 1 Line-out |
| イーサネット | |
| LAN 1 | Intel® I226 2.5GigE LAN supports TSN |
| LAN 2 | Intel® I226 2.5GigE LAN supports TSN |
| 電源 | |
| 入力電圧 |
DC 16V to 50V
|
| インタフェース |
4-pin Terminal Block : V+, V+, V-, V-
|
| イグニッション コントロール |
16-mode Software Ignition Control |
| リモートスイッチ | 3-pin Terminal Block |
| Out-of-Band 管理 | |
| MCU | Nuvoton NUC980 |
| インタフェース | OOB LAN, 10/100Mb Ethernet LAN, RJ45 Connector |
| リモート制御 | Support Remote Power ON/OFF, Reset and Power Cycling |
| その他 | |
| TPM | Infineon SLB9670 supports TPM 2.0, SPI Interface |
| ウォッチドッグ タイマ (WDT) |
Reset : 1 to 255 sec./min. per step |
| 遠隔制御 | Wake on LAN, PXE supported |
| HW Monitor | Monitoring temperature, voltages. Auto throttling control when CPU overheats. |
| メカニカル設計 | |
| 外形寸法 | |
| 質量 |
10.2 kg (22.5lb)
|
| マウント | – Wallmount by mounting bracket – Rackmount (Optional) |
| 設置環境条件 | |
| 動作温度 |
With GPU: -25°C to 45°C (-13 °F to 113 °F), with air flow
Without GPU: -25°C to 60°C (-13 °F to 140 °F), with air flow
|
| 保存温度 | -25°C to 85°C (-13°F to 185°F) |
| 湿度 | 5% to 95% Humidity, non-condensing |
| 相対湿度 | 95% @45°C |
| 耐衝撃性 耐振動性 |
– IEC 61373 : 2010
– Railway Applications : Rolling Stock Equipment, Shock and Vibration Tests
|
| EMC指令 | CE, FCC, EN50155, EN50121-3-2 |
